Double Twister Line
Double Twister Line
It has an important place in the sector with its product quality, production speed, low cost and practical use advantages. There are various models available according to the reel size.
Buncher twisting process performs high strength and smooth twisting of cables. It provides production variety with its wide cross-section range.
It provides higher work safety with protection cages that provide safe sound insulation and operator comfort.
| Model | BNC630 | BNC800 | BNC1250 | BNC1600 | BNC2000 |
|---|---|---|---|---|---|
| Maximum Reel Diameter | Ø630 | Ø800 | Ø1250 | Ø1600 | Ø2000 |
| Minimum Reel Diameter | Ø560 | Ø630 | Ø800 | Ø1250 | Ø1600 |
| Maximum Twisting Speed | 6500 twist/min | 5000 twist/min | 2000 twist/min | 1200 twist/min | 1000 twist/min |
| Maximum Line Speed | 300 m/min | 300 m/min | 300 m/min | 200 m/min | 150 m/min |
| Twisting Cross-Section Range mm² | 0.09-6 mm² | 0.25-16 mm² | 10-120 mm² | 10-185 mm² | 16-400 mm² |
| Maximum Product Diameter | 25 mm | 30 mm | 30 mm |
